10heads weigher (1.6L)
10heads weigher
- Model：
1. Application:
It is suitable for weighing of granule, slice, roll or irregular shape materials such as cereal, pasta, candy, seed, chips, coffee bean, nut, puffy food, biscuit, chocolate, pet food, frozen foods, etc. It is also suitable for non-food industry such as screws, bolts and plastic components.
2. Main Features:
* Amplitude can be adjusted freely and individually in running status, more friendly HMI.
* Multi-language operating interface.
* Mouse, USB and SD card compatible with touch screen.
* Stagger dump prevents products blockage
3. Special Features:
* Modular electronic system makes maintenance easier and at lowest cost
* AD card are inter-changeable ,easy to be replaced ；
* Different authority managements, more user- friendly
* HMI can be upgraded by U disk
Specifications
Model | TO-1A-M10L1.6 |
Max.Cap.(g) | 10-2000g |
Weighing Accuracy | 0.1-1.5g |
Weighing Speed | 120WPM |
Hopper Capacity | 1600ml |
Control System | MCU |
Operation Panel | 7 inch touch screen |
Power Supply | AC220V/110V ±10% ，50Hz(60Hz) |
Packing Dimension (mm) | 1790(L)×1270(W)×1300(H) |
Gross Weight | 450KG |
